OC family tag


M-OC-C8s: Module with eight OC outputs and an RGBW controller functionality

Module M-OC-C8s is a component of the Ampio Smart Home system. Required voltage to power the module is 11 — 16V DC. The module is controlled via CAN bus. The module has eight OC outputs, eight ground-detecting inputs and supports the functionality of an RGBW lighting controller.

Last update July 28, 2022, tags: Ampio CAN modules, OC family, Integrations, Output modules, DIN rail modules, Lights, LED lights, RGBW lights, Open-collector drivers, Central heating, Security, Wall switch

M-OC-32s: Module with thirty-two bi-state OC outputs

Module M-OC-32s is a component of the Ampio Smart Home system. Required voltage to power the module is 11 — 16V DC. The module is controlled via CAN bus. The module has thirty-two two-state OC outputs. Bi-state OC outputs The module has open-collector outputs allowing for switching of resistive loads supplied with voltage up to 40V DC.

Last update July 13, 2022, tags: Ampio CAN modules, OC family, Output modules, DIN rail modules, Lights, LED lights, Open-collector drivers, Central heating

M-OC-4s: Module with four OC outputs and an RGBW controller functionality MRGBWOC-4s

Module M-OC-4s is a component of the Ampio Smart Home system. Required voltage to power the module is 11 — 16V DC. The module is controlled via CAN bus. The module has four OC outputs and supports the functionality of an RGBW lighting controller.

Last update July 13, 2022, tags: Ampio CAN modules, OC family, Output modules, DIN rail modules, Lights, LED lights, RGBW lights, Open-collector drivers, Central heating

M-INOC-4p: Module with four bi-state inputs, four OC outputs and an RGBW controller functionality MRGBWOC-4p

Module M-INOC-4p is a component of the Ampio Smart Home system. Required voltage to power the module is 11 — 16V DC. The module is controlled via CAN bus. The module has four ground-detecting inputs, four OC outputs, and a 1-Wire interface.

Last update July 13, 2022, tags: Ampio CAN modules, IN family, OC family, Wall switch, Sensors, Dallas 18B20, Input modules, Output modules, Junction box modules, Lights, LED lights, RGBW lights, Open-collector drivers, Central heating

M-INOC-8s: Module with eight bi-state inputs and eight OC outputs

Module M-INOC-8s is a component of the Ampio Smart Home system. Required voltage to power the module is 11 — 16V DC. The module is controlled via CAN bus. The module has eight ground-detecting inputs, eight OC outputs, and a 1-Wire interface.

Last update July 13, 2022, tags: Ampio CAN modules, IN family, OC family, Wall switch, Sensors, Dallas 18B20, Input modules, Output modules, DIN rail modules, Lights, LED lights, Open-collector drivers, Central heating

M-OUT-4s configuration guide

The M-OUT-4s module is equipped with voltage analogue outputs that allow it to integrate with devices that have voltage control inputs. This document explains how the module’s configuration is carried out.

Last update April 8, 2022, tags: Configuration, Smart Home configurator, OC family

WL-OC-RGBW1p: Wireless RGBW lighting controller RF RGBW-1p

Module WL-OC-RGBW1p is a component of the Ampio Smart Home system. Required voltage to power the module is 11 — 16V DC. The module is controlled via the Ampio LoRa wireless interface. The module has four OC outputs operating in an RGBW lighting controller mode.

Last update February 23, 2022, tags: Ampio LoRa wireless modules, OC family, Junction box modules, Output modules, Lights, LED lights, RGBW lights, Wireless, LoRa
